How to Install Bodaq Interior FIlm

↑ WATCH INSTALLATION MANUAL ↑

Video Lessons From Our Partner

How to Install
Bodaq Interior FIlm

Video Lessons From Our Partner

Bodaq Film Installation Instructions

Bodaq Film
Installation Instructions

01

create a smooth, flat surface

If needed, create a smooth, flat surface using putty followed by light sanding.

02

Apply the primer on the surface for better adhesion

Apply the primer on the surface for better adhesion, then apply around edges and corners, lightly sand when dry. Primer application requirements varies depending on the surface, for detailed instructions – contact our technical department.

03

Measure and cut the BODAQ interior film

Measure and cut the BODAQ interior film.

04

Peel off and pull the release backing

Peel off and pull the release backing about 4 inches and attach the firmly attach the film, repositioning as needed until properly aligned.

05

adhere the film from top to bottom

Using a squeegee held at a 45 degree angle, firmly adhere the film from top to bottom using a fan-shaped sweeping motion.

Bodaq Film Installation Information

Before installing BODAQ films, please review the following information concerning the storage and handling of our products to maintain its high quality.

Check the Surface Type

CHECK THE CONDITION AND TYPE OF SURFACE BEFORE APPLYING

  • Adhesion can be weakened due to moisture. If installing on non-solid surfaces like MDF or drywall make sure to remove moisture (e.g. increase room temperature to 60-75 degrees (F) / 15~25°C for 12-24 hours.
  • Post-installation protect substrate from moisture intrusion which can weaken the adhesive bond.
  • If product has been stored outdoors in cooler weather open the carton and store the product indoors between 60-75 degrees (F) / 15~25°C for 12-24 hours. Installation of film that is below 60 degrees (F) / 15°C may result in adhesive cracking or weakening.
  • Note that any residual oil, wax, or other surface contaminants can weaken the adhesive bond between the BODAQ adhesive and the substrate.
Using Primer

USING PRIMER

  • BODAQ recommends the use of a primer applied to any non-solid surface. Adhesion around edges and corners of any surface will be enhanced by use of a primer. Contact us to get recommendations regarding available primers.
  • After using a primer, allow at least two hours before applying BODAQ film.
Product Application

PRODUCT APPLICATION

  • To prevent creasing, stretching, or tearing use minimum force when using a squeegee and/or using heat to apply the product to flat or curved surfaces.
  • Consider using additional pressure when applying thick patterns like artificial leather, papers, or stone.
Storing Bodaq Film

STORING BODAQ FILMS

  • Store BODAQ films in the original shipping carton to avoid denting the roll or damaging the surface of the film.
  • Store BODAQ film between 60 and 75 degrees F (15~25°C) if possible and below 50% relative humidity and out of the direct rays of the sun.
  • BODAQ interior film should not be used for exterior applications.
  • After installation, extended exposure to ultra violet radiation can cause discoloration.
  • Although the surface of BODAQ film is very durable, it should be protected from repeated or severe abrasion.
